Switch type:

Managed

Switch layer:

L3

Quality of Service (QoS) support:

Yes

Web-based management:

Yes

ARP inspection:

Yes

MIB support:

RFC 1213; RFC 4188; RFC 1157, 2571-2576; RFC 1907; RFC 1757, 2819; RFC 2021; RFC 1398, 1643, 1650, 2358, 2665; RFC 2674 802.1p 2233, 2863 IF MIB; RFC 2618; RFC 2620; RFC 2925; RFC 2674, 4363; RFC 1065, 1066, 1155, 1156, 2578; RFC 1215; RFC 1212; RFC 1215; RFC 1157, 2571-2576; RFC 4022; RFC 4113; RFC 4293; RFC 2737

Basic switching RJ-45 Ethernet ports quantity:

24

Basic switching RJ-45 Ethernet ports type:

Gigabit Ethernet (10/100/1000)

SFP+ module slots quantity:

4

Fiber optic connector:

SFP+

USB 2.0 ports quantity:

1

Power connector:

AC-in jack

Networking standards:

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3x

10G support:

Yes

Copper ethernet cabling technology:

10BASE-T, 10GBASE-T, 100BASE-T, 1000BASE-T

Port mirroring:

Yes

Flow control support:

Yes

Link aggregation:

Yes

Spanning tree protocol:

Yes

Head-of-line (HOL) blocking:

Yes

VLAN support:

Yes

Virtual LAN features:

MAC address-based VLAN, Port-based VLAN, Private VLAN, Tagged VLAN, Voice VLAN

Number of VLANs:

4000

Switching capacity:

168 Gbit/s

Forwarding rate:

125 Mpps

MAC address table:

16384 entries

Jumbo frames support:

Yes

Jumbo frames:

9000

Packet buffer memory:

2 MB

DHCP features:

DHCP client, DHCP relay, DHCP server, DHCP snooping

Access Control List (ACL):

Yes

Access Control List (ACL) egress:

512

Access Control List (ACL) ingress:

2048

IGMP snooping:

Yes

SSH/SSL support:

Yes

Loop protection:

Yes

BPDU filtering/protection:

Yes

Authentication:

Guest VLAN, MAC-based authentication, Port-based authentication

Queue scheduling algorithms:

Deficit weighted round robin (DWRR), SP, WRR+SP, Weighted Round Robin (WRR)

Multicast support:

Yes

Routing protocols:

RIP

Stackable:

Yes

Product colour:

Grey

LED indicators:

Yes

Number of fans:

1 fan(s)

Certification:

FCC A, CE A, VCCI A, IC, RCM, BSMI, CCC

Physical stacking (units):

9

Virtual stacking (units):

32

Noise level:

47 dB

Mean time between failures (MTBF):

388361 h

Redundant power supply (RPS) support:

Yes

AC input voltage:

100 - 240 V

AC input frequency:

50 - 60 Hz

Power consumption (max):

30.36 W

Power over Ethernet (PoE):

No

Operating temperature (T-T):

0 - 50 °C

Storage temperature (T-T):

-40 - 70 °C

Operating relative humidity (H-H):

10 - 90%

Storage relative humidity (H-H):

5 - 90%

Heat dissipation:

103.59 BTU/h

Width:

440 mm

Depth:

250 mm

Height:

44 mm

Weight:

3.2 kg
